2017 - BANDIT - 3680 Call for Price


See Spec Document for BANDIT 3680 See Brochure for BANDIT 3680



BANDIT MODEL 3680TRA TRACK-BEAST RECYCLER. CATERPILLAR C27, 875 HP DIESEL ENGINE WITHOUT CLUTCH, TIER 2 (INCLUDES REVERSING FAN) HORIZONTAL FEED WITH A 42" DIAMETER CUT RADIUS AND A 63" WIDE CUTTER MILL. REPLACEABLE CUTTER ANVIL 24" DIAMETER X 60" WIDE TOP FEED WHEEL. DRIVEN BY (1) 12.2 CUBIC INCH HYDRAULIC MOTOR WITH GEARBOX. ALSO FEATURES 1 3/4" FEED WHEEL TEETH LOCATED AROUND AND ON THE SIDES OF FEED WHEEL. REVERSING AUTO FEED SYSTEM. DEBRIS AUGERS RADIO REMOTE CONTROL WITH TETHER REMOTE BACK UP AND 50' OF CORD. (CONTROLS YOKE UP,INFEED CONVEYOR FORWARD/REVERSE, DISCHARGE CONVEYOR START/STOP, ENGINE THROTTLE, TRACK FUNCTIONS AND ENGINE STOP). 14'6" LONG X 60" WIDE DOUBLE SLAT DESIGN TRACK-TYPE INFEED CONVEYOR BED CHAIN WITH THREE SPEED DRIVE (18-43 FPM). DRIVEN BY (1) 24 CU IN HYDRAULIC MOTOR WITH GEAR BOX/CHAIN DRIVE COMBINATION.(INCLUDES STEEL FOLD DOWN TRAY) ELECTRIC OVER HYDRAULIC SHUT DOWN SWITCHES LOCATED ON ALL FOUR CORNERS OF MACHINE. HIGH CAPACITY FOLD AWAY RADIATOR DEBRIS SCREEN. 150 GALLON HYDRAULIC TANK, WITH MAGNETIC DRAIN PLUG AND ALUMINUM FLUID SIGHT GAUGE. 300 GALLON FUEL TANK WITH MAGNETIC DRAIN PLUG AND ALUMINUM FLUID SIGHT GAUGE. SAFETY DVD, (2) 6"X9" BANDIT OPERATOR MANUALS (ONE PAPER COPY AND ONE WATERPROOF COPY TETHERED TO MACHINE). ONE ENGINE OPERATOR'S MANUAL. FIRE EXTINGUISHER WITH MOUNT. LOCKABLE CONTROL CABINETS WITH ENGINE CONTROL PANEL. SCREEN CHANGING ARM. BANDED KEVLAR DRIVE BELTS WITH BELT SHIELD. LIQUID DUST SUPPRESSION SYSTEM WITH SPRAY NOZZLES (3)HEAT ACTUATED FIRE SUPPRESSION BOMBS. STANDARD IMRON INDUSTRIAL URETHANE BANDIT YELLOW.(CHIPPER GUARD PAINT COLOR YELLOW) 27-1/2' LONG X 4' WIDE SINGLE SPEED (280 FPM) HEIGHT ADJUSTABLE DISCHARGE SYSTEM. DISCHARGE WILL GO DOWN 20 DEGREES AND UP 32 DEGREES. (MAX STACKING HEIGHT 15') HPTO15 PT TECH FLUID CLUTCH HIGH HORSEPOWER CUTTERHEAD OPTION FOR ENGINES ABOVE 540 HP. CAT MODEL 325EL STEEL TRACK UNDERCARRAIGE W/ HD DRIVE TRIPLE GROUSER (700MM, 27 1/2" WIDE TRACK PADS) 30 TOOTH CUTTERMILL IN LIEU OF 60 TOOTH. (30)TOOTH STYLE CUTTERBODY 2" WIDE DOUBLE 1" FLAT CARBIDE FAN TOOTH. 3/4" THICK, 3" MODIFIED DIAMOND SCREEN TO BE INSTALLED ON MACHINE. 2" MODIFIED, 18" GATE 875 RPM CUTTERMILL 29 1/2 " DIAMETER X 60" WIDE TOP FEED WHEEL. ALSO FEATURES 1 3/4" FEED WHEEL TEETH LOCATED AROUND AND ON SIDES OF FEED WHEEL. PROPORTIONAL HYDRAULIC FEED SYSTEM ENGINE PRE-CLEANER- ENGINE AIR. MAGNETIC HEAD PULLEY. 36 POINT AUTOMATIC GREASER SYSTEM W/ TIMER. AIR COMPRESSOR WITH 13 HP HONDA GAS ENGINE, BATTERY DSICONNECT, 50' HOSE, & 24GALLON TANK. ALSO INCLUDES: (1) INGERSOLL RAND MODEL IR2141 (3/4" DRIVE) AIR WRENCH, (1) 1-1/2" IMPACT SOCKET FOR CUTTERBODY BOLTS, (1) 1-15/16" IMPACT SOCKET FOR TOOTH NUTS, (1) 1-1/8" IMPACT SOCKET, & QUICK COUPLERS & HOSE. 54" DIAMETER FLEXXAIRE FULL VARIABLE PITCH AUTO REVERSING COOLING FAN FOR CAT C27 ENGINES.
