2017 - BANDIT - 3590 $593,780


See Spec Document for BANDIT 3590 See Brochure for BANDIT 3590



BANDIT MODEL 3590 (30" DRUM STYLE) TOWABLE WHOLE TREE CHIPPER. POWERED BY A CAT C27,875 HORSEPOWER DIESEL ENGINE, WITHOUT CLUTCH -TIER 2 (INCLUDES CATERPILLAR 5 YEAR/5,000 HOUR "PLATINUM" ENGINE WARRANTY). BANDIT CONTROL PANEL REVERSING AUTO FEED SYSTEM (2) HYDRAULIC LIFT CYLINDERS. SLIDE BOX (CHAIN DRIVEN)FEED SYSTEM WITH (2) TOP FEED WHEELS. INCLUDES (1) 36" WIDE X 15 3/4" DIAMETER TOP FEED WHEEL, ALONG WITH A 36" WIDE X 10 5/8" DIAMETER TOP CLIMBER FEED WHEEL. ALSO INCLUDES (2) VERTICAL SIDE FEED WHEELS 46" HIGH X 11 1/4" DIAMETER, THIS INCLUDES SUPPORT PLATES BEHIND THE VERTICAL FEED WHEELS. BOTTOM FEED WHEEL DEBRIS DEFLECTOR ON TOP YOKE FOR FEED WHEELS RADIO REMOTE CONTROL WITH TETHER REMOTE AND 30' CORD. REMOTE CONTROLS THE FOLLOWING FUNCTIONS(DISCHARGE FUNCTIONS, FEED SYSTEM FORWARD/REVERSE, YOKE UP/DOWN, THROTTLE AND ENGINE KILL SWITCH) WIDE PROFILE TAPERED INFEED HOPPER WITH 14' LONG INFEED CONVEYOR AND HEAVY-DUTY TRACK STYLE INFEED CHAIN. ENGINE START PANEL STATIONARY DISCHARGE SYSTEM WITH UP & DOWN (50 DEGREES)AND SIDE TO SIDE(50 DEGREES) CHIP DEFLECTOR, HYDRAULICALLY OPERATED. ALSO INCLUDES (2) BOTTOM CLEAN OUT INSPECTION DOORS. TOP OF DISCHARGE FEATURES REPLACEABLE AR STEEL. (3) TOGGLE SWITCHES TO CONTROL DISCHARGE TO BE LOCATED ON INSTRUMENT PANEL. 37" DIAMETER X 48" WIDE CHIPPER DRUM WITH (8) 5/8" X 6" X 12 1/8" BABBITED KNIVES, (8) 3/8" X 6" X 12 1/8" COUNTER KNIVES. IN-LINE HYDRAULIC PRESSURE CHECK SYSTEM. 200 GALLON STEEL HYDRAULIC TANK WITH MAGNETIC DRAIN PLUG, LOCKABLE FILLER CAP, MESH SCREEN STRAINER AND GATE VALVE. 350 GALLON STEEL FUEL TANK WITH MAGNETIC DRAIN PLUG, LOCKABLE FILLER CAP, ALUMINUM SIGHT GAUGE AND FUEL SHUT OFF VALVE. (2) HYDRAULIC STABILIZERS WITH FIFTH WHEEL HITCH FOR TOWING 24 VOLT SYSTEM (INCLUDES(2)1,400 CCA BATTERIES), WITH REMOVABLE LED TAIL LIGHTS, PROTECTED JUNCTION BOX AND LED SIDE CLEARANCE LIGHTS AND REFLECTORS BANDED CHIPPER DRIVE BELTS ENGINE DISABLE PLUG FOR HOOD LOCKING PIN-PREVENTING ENGINE FROM OPERATING WITHOUT PIN IN PLACE. SAFETY DVD, (2) 6" X 9" BANDIT OPERATOR'S MANUALS (ONE PAPERCOPY AND ONE WATERPROOF COPY TETHERED TO MACHINE) AND ONE ENGINE OPERATOR'S MANUAL. SPANISH AND ENGLISH COMBINATION SAFETY DECALS. 2 1/2 POUND FIRE EXTINGUISHER. STANDARD IMRON INDUSTRIAL URETHANE BLACK. CHIPPER GUARD COLOR GRAY. HPTO18 DRY CLUTCH (PUSH BUTTON ENGAGE). (2) 25,000 POUND AIR BRAKE AXLES. (8) 11R X 22.5, 16 PLY TIRES MOUNTED ON 10-BOLT STEEL DUAL RIMS. ENGINE PRE-CLEANER- ENGINE AIR. DELUXE LIGHT PACKAGE INCLUDES: (7) HELLA WORKLAMP LIGHTS, (2) ARE MOUNTED AT THE TOP OF THE INFEED ON EACH SIDE, (2) ARE MOUNTED ON EACH SIDE OF THE INFEED CONVEYOR, (2) ON EACH SIDE OF THE DISCHARGE CHUTE AND (1) ON TOP OF THE DRUM/DISC HOOD. CORDLESS 1/2" IMPACT WRENCH 4.0 HORSEPOWER MINI AIR COMPRESSOR BANDIT 5 YEAR "GUTS" WARRANTY (INCLUDES COVERAGE ON BANDIT MANUFACTURED COMPONENTS ON THE DRUM/DISC AND SLIDE BOX FEED SYSTEM.
